Electro-hydraulic Servo Manhole Cover Testing Machine
[rank_math_breadcrumb]
Electro-hydraulic Servo Manhole Cover Testing Machine
The microcomputer electro-hydraulic servo manhole cover pressure testing machine is used for testing the bearing capacity(residual deformation and test load) of various materials manhole covers,which can realize the closed loop control of constant rate loading and constant rate deformation, etc., it can realize the automatic calculation of the technical index of the test piece.
| Max test force | 600kn | 1000kn |
| Accuracy | 1 | 1 |
| Deformation measurement resolution | 0.001mm | 0.001mm |
| Maximum spacing | 400mm | 400mm |
| Maximum speeding | 120mm/min | 80mm/min |
| Size of upper platen | 250mm | 250mm |
| Size of lower platen | 356mm | 356mm |
| Host size | 1220*1050*2100mm | 1420*1250*2120mm |
| Control cabinet size | 800*600*1600mm | 800*600*1600mm |
| Host weight | 300kg | 300kg |
| Control cabinet weight | 2500kg | 300kg |
