Fire extinguisher spraying laboratory

This chamber is designed and manufactured to meet the national standard G8 4351.1-2005 “Portable Fire Extinguishers Part 1: Performance and Structural Requirements” in the spray test requirements, so that the spray test in a closed environment, eliminating environmental interference, thereby improving the reliability of the test. It is suitable for fire extinguisher spraying performance test: spraying time, spraying lag time, spraying distance, spraying residual rate test. Suitable for all levels of local quality supervision and testing departments and fire extinguisher manufacturers to use.

Technical Parameters

1.Laboratory dimensions:LxWxH 16500mmx4000mmx2100mm
2. Jet room size: LxWxH 14500mmx3700mmx2000mm
3. Jet port: 1000mm from the ground, LxW:500mmx500mm.
4.Independent spraying operation room:2000mm*3700mm*2000mm
5.Time precision:1s
6.Mass accuracy:1g
7.Black ruler:2pcs
