Mechanical Impact Test Bench

Mechanical impact test bench is based on GB5135.3-2003 “automatic sprinkler system Part 3: water spray nozzle” in the water spray nozzle mechanical impact test requirements, will be 5 probe specimens were normally installed in the positive and negative direction and the direction of the vertical plane is fixed in the mechanical impact table, the impact acceleration of 100g, in each direction, 3 times the impact.

Technical Parameters

1. Steel ball weight 100g, error ±5g
2. Control and lifting mode: electrical control electromagnetic suction cup, electric lifting height
3. Drop height:0~1500mm adjustable
4. Sample frame workspace: 400x350mm
5. Sample clamping mode: fixture clamping
6.Thickness of falling steel plate:10mm
7.Power supply:220V/1.5kw
8.Instrument size:1050mm*600mm*2150mm
