W-Series Manual Video Measuring Machine
● With “HIWIN” P level linear guideway and
precision cross roller guideway for increased
accuracy & working life.
● Supplied with SBK-E multifunctional 2.5D measuring software, automatic edge detec tion and vision height measurement function.
● Supplied with removable & dismountable
console support table.
● High-definition detent step zoom lens and
high-resolution CCD performs high-definition measurement.
● Supports different file formats of data output such as Word, Excel, CAD etc. DXF import for quick inspection.
|
Measuring range(mm)
|
300×200×200
|
|||
|
Machine size(mm)
|
1050×845×1285
|
|||
|
Weight(kg)
|
190
|
|||
|
Max. load(kg)
|
20
|
|||
|
Accuracy of X-Y axis(μm)
|
3.0+L/200
|
|||
|
Accuracy of Z axis(μm)
|
5.0+L/200
|
|||
|
XYZ resolution(μm)
|
1.0
|
|||
|
Repeatability(mm)
|
0.003
|
|||
|
Linear encoder
|
glass linear scale
|
|||
|
Camera type
|
SBK-HC536 1/3 inches 600 lines industrial color camera
|
|||
|
Liner guide
|
Z axis: Taiwan“HIWIN” P grade linear guideway; XY use “V” type linear guideway
|
|||
|
Optics
|
6:5:1 continual zoom step lens
|
|||
|
Magnification
|
optics zoom ratio: 0.7-4.5X; image zoom ratio: 24-158X
|
|||
|
Software
|
SBK-E manual 2.5D measure software
|
|||
|
Control system
|
SBK3000 control box, USB port, adjustable light
|
|||
|
Profile illumination
|
LED cold lighting,256 level programmable brightness adjustment
|
|||
|
Surface illumination
|
LED cold lighting with segmented independent control & 256 level programmable brightness adjustment
|
|||
|
Operated mode
|
handle wheel
|
|||
