Rock Grinding Machine Concrete Double End Face Grinding Machine

Main technical indicators
1,Workbench motor power: 0.55KW
Speed speed of :1,450 rpm
2,Grinding power head capability: 1.1KWx2 unit rotation speed of 2,800 rpm
3,Minding wheel diameter: Φ200mm
4,Mable sample specification: (50-100mm clamture)
a: block: 50x50x50-150x150x150mm
b: cylinder: Φ50-Φ150mm
5,Sample accuracy:
a: Plane: ± 0.05mm, Vertical ≤ 0.1mm;
b: finish: (by machining roughness) Ra3.2
6,Automatic grinding feed: 0.08-0.4mm adjustable
7,Cooling device: tap water cooling

The double-end face grinder machine is the main equipment necessary for the production of standard samples for mechanical testing of various rock, mineral, concrete and other non-metallic solids. This machine works with the coring machine and rock cutting machine produced by our factory to process the high-precision cube or cylinder test samples you need. It is suitable for departments such as colleges and universities, water conservancy and hydropower, geology and minerals, transportation, and construction.

The machine is composed of a base table, a grinding power head, a variable speed transmission system, and an electric control device. The whole machine is easy to operate, and the automatic feed performance is stable.
