Schmidt Rebound Hammer for Concrete strength test
1.High strength center rod 2. High Aluminum case extend use life. 3. High accuracy and durable resistance 4. Pointer slider is outside structure, its friction can be balance well and easy to be adjusted so that we can make sure that the instrument is accurate
|
Standard impact energy
|
2.207±0.1J (0.225Kgf.m)
|
|||
|
Pointer friction force
|
0.65N±0.15N
|
|||
|
Pointer length
|
20±0.2mm
|
|||
|
Tension spring rigidity
|
785±40(N/m)
|
|||
|
Hammer inpact length
|
75±0.3mm
|
|||
|
Tension spring working length
|
61.5±0.3mm
|
|||
|
Fixed value of steel anvil
|
80±2
|
|||
|
Measuring Range
|
10~70Mpa
|
|||
|
Radius of spherical tip
|
25mm±1mm
|
|||
|
Working Temperature/ Humidity
|
-10℃~+50℃/ ≤90%RH
|
|||
|
Dimensions
|
Φ54x280mm
|
|||
|
Net weight
|
1Kg
|
|||
