Triaxial Testing Machine Bench Light duty Universal Shear Strain Controlled Soil Triaxial Test Apparatus
[rank_math_breadcrumb]
Triaxial Testing Machine Bench Light duty Universal Shear Strain Controlled Soil Triaxial Test Apparatus
| Sample dimension | dia. 39.1×80 mm |
| Max load | 10Kn |
| Strain rate | 0.016-1.6mm/min. six-speed mechanicaltransmission |
| Table stroke | Max. 50mm |
| Confining pressure | 0-1Mpa |
| Back pressure | 0-0.6Mpa |
|
Hole pressure |
0-1Mpa |
| Volume change | 0-25ml |
| Graduation | 0.1ml |
| Axial displacement | 0-30mm |
| Power | 220V±10%, 50Hz |
| Machine dimension | 350 x 300 x 1100mm |
| Controller Dimension | 500 x 500 x 925mm |
